Live Tools for Star CNC, Citizen &Tsugami
from Swistek Machinery America
www.swistek.com | 'The Best Components' 'The Best Value' |
ISMS is pleased to offer Star CNC Swiss live tools, Citizen Swiss live tools, & Tsugami Swiss live tools from Swistek Machinery America
Download Swiss Live Tool Catalog
(Adobe PDF - 7.7MB)
| Live Tools for Star CNC
Star CNC is one of the biggest Swiss Screw Machine manufacturers in the world. We carry a broad range of live tools for Star Sliding Headstock CNC Lathes that will help you get the job done no matter what you’re producing.
We stock popular Star CNC Swiss live tools. Contact ISMS to check inventory & pricing.
| Live Tools for Tsugami
Tsugami machines are some of the most precise in the Swiss CNC Screw Machine business. We have a full supply of Tsugami live tools that will allow you to adapt and modify your machines for any kind of unit production. | Live Tools for Citizen Swiss
Japan-based Citizen is a major player in the Swiss CNC screw machine market. We carry an array of parts of Citizen machines so you can tackle your next job quickly and efficiently. Download Swiss Live Tooling Catalog (PDF - 4.6MB) Contact ISMS for pricing or to place an order.
| Live tools for SWISTEK, MIYANO, GANESH, NOMURA, HANWHA, DOOSAN, NAKAMURA & NEXTURN Swiss turning centers are also available.Please check out our catalog. | Live tools allow turning machines to perform secondary operations like milling, drilling, or tapping either on the face or around the diameter of a workpiece. This works in tandem with the main spindle, which provides indexing in precise increments and allows for easy repeatability, which saves time and helps machine shops create more parts. Live tools are key to completing any job. It doesn’t matter if you are drilling, milling, or tapping, you need the right tool to make the right part. Swistek offers a broad range of live tools that will work with whatever Swiss machines you might have in your shop Download Swiss Live Tool Catalog
(Adobe PDF - 4.5MB) |
|
|
